Mean Well 150 Watt Power Supply

$26.00$49.00

Overview
Authentic Mean Well brand LRS-150 150W Single Output Switching Power Supply

  • Wattage: 150W
  • Input: 115/230VAC
  • Output: 12 or 24 VDC
  • Warranty: 3 Years
SKU: N/A Categories: ,

Authentic Mean Well 150W Single Output Switching Power Supply. For complete details, download the LRS-150-SPEC

Features

  • Selectable AC input range switch
  • Able to withstand 300VAC surge for 5 seconds
  • No load power consumption for less than 0.5 watts
  • Small size and 1U low profile
  • Supports operating temperature up to 70 C
  • Short circuit, overload, over voltage, and over temperature protections
  • Free air convection cooling
  • Compliance standards: IEC/BS EN/EN 60335-1 (PD3) and IEC/BS EN/EN61558-1, 2-16 for household appliances
  • Tested to 5G vibration
  • High efficiency, long life, and high reliability
  • LED indicator for power on
  • Over voltage category III
  • 100% full burn in testing
  • 3 year warranty

Description

The LRS-150 series is a 150W single-output enclosed type power supply. It has a 30mm low profile design. The input is selectable for 115VAC or 230VAC using the switch on the side. This unit is available with an output voltage of either 12V or 24V. It is 90% efficient and the design of the metallic mesh case enhances heat dissipation so the whole series can operate from -30C to 70C under air convection without a fan. The entire system easily meets worldwide energy requirements.

Weight 2 lbs
Dimensions 12 × 6 × 6 in
Voltage

24, 12
